The Flow Editor (Magic xpi 3.x)
You create a flow by inserting flows into the Flow Editor. The Flow Editor has Trigger and Flow areas. Components that trigger a flow automatically are placed in the Trigger area. Components that are part of the flow are placed in the main flow area. The flow is executed in the order that you place the components. However, you can move a branch of components to change the branch order.
In addition, you can create flow logic, which sets conditions and rules for the execution of the flow.
The following table shows the various display items that you may see in the Flow Editor:
|
|
|
Indicates that a step’s Wait for Completion parameter is set to Yes.
|
|
A small blue square to the left of a component icon indicates that the component has not been configured.
|
|
Processing mode:
-
A solid line indicates a linear connection between steps.
-
A dotted line indicates a parallel connection between steps.
-
A broken line indicates a stand-alone connection between steps.
|
|
When marking a flow as auto start, the Auto Start icon will appear above the Trigger area.
|
|
When marking a flow as auto repeat, the Auto Repeat icon will appear above the Trigger area.
|
|
When a step has a breakpoint defined, a red dot will appear next to the step.
|
|
When a step is defined as suspended, an X will appear next to it.
|
|
The GoTo icon indicates that this step is actually a pointer to another step in the flow. This is a simple way to reuse code that already exists in the flow.
When you select the component that goes to another component, Magic xpi displays a dashed line pointing to the component to be executed next.
|
The following table describes the elements in the Flow Editor.
|
|
Instances/Steps
|
-
You can drag one or more components from the Components Pane into a flow. Each component represents an instance or step in a flow.
-
You can press Ctrl+F or go to the Edit menu and select Find Name to open the Find dialog box. You can use this functionality to find the first step that contains the search string.
|
Processing Mode
|
-
A flow can only execute one linear path, or branch, at a time. You can determine this path using flow logic.
-
A flow can have several parallel steps in each level of the flow.
|
Collapse/Expand Branches
|
-
If you have created long flows in the Flow Editor, you can collapse and expand the various branches. This allows you to see more of the flow without scrolling down.
-
To collapse a branch, you should right-click on the first step of the branch that you want to collapse, and select Collapse from the context menu.
-
If you want to reverse this, you should right-click on the step, and select Expand or Expand All from the context menu. A plus (+) sign next to the step indicates that the branch can be expanded. A minus (-) sign indicates that the branch can be collapsed.
-
When you collapse a branch, all steps and branches under the selected step are collapsed.
-
The state of the last collapsed or expanded steps are saved in an external file outside the project. When you open a project, the previous state of the branches is restored using the data that was saved to the file.
-
You can also collapse or expand branches by parking on the relevant step and selecting Collapse or Expand from the Edit menu.
Since version: V3
|
Flow Logic
|
|
Text Areas
|
-
You can use a Text Area to add labels to identify the various steps that form a flow.
-
Insert a Text Area by selecting Text Area from the Insert menu. Once you select the tool, you then draw the Text Area where required and enter the desired text.
-
You can resize the Text Area by selecting the area and dragging the sizing handle to the desired size.
-
You can minimize or maximize Text Areas by selecting either Minimize All Text Areas or Maximize All Text Areas from the Edit menu.
|
